Diamond Pro® Air Wall System
Face Styles
Heritage
Straight Face
Smooth Face
Quarried Face
*Not reflective of colors available in your region
-
System Performance
- Max. Gravity Wall Height 3’6”
- System Batter 4°
- Min Inside Radius 6’0”
- Min Outside Radius 4’0”
Applications- Terraced Walls
- Commercial
- Residential
Blocks
Diamond Pro Air Smooth Face- Height 8"
- Front Length 1'6"
- Depth 0’11”
- Weight 54 lbs
- Front Coverage 0.06 sq. ft.
- Setback 4°
Diamond Pro Air Quarried Face- Height 8"
- Front Length 1'6"
- Depth 11.5"
- Weight 54 lbs
- Front Coverage 0.06 sq. ft.
- Setback 4°
DIamond Pro Air Straight Face- Height 8"
- Front Length 1'6"
- Depth 11.5"
- Weight 54 lbs
- Front Coverage 0.06 sq. ft.
8" Corner- Height 0’8”
- Front Length 1’6”
- Depth 0’9”
- Weight 101 lbs
- Front Coverage 1.0 sq. ft.
Cap- Height 0’4”
- Front Length 1’5”
- Depth 0’10”
- Weight 47 lbs
- Front Coverage 0.48 sq. ft.
